Transmission Sensor
| Ref No. | Parts No. | Parts Name |
| 1 | 1A710-5M4-003 | ATF TEMPERATURE SENSOR |
| 2 | 22713-5M4-000 | FEED PIPE GUIDE A |
| 3 | 22715-5M4-000 | FEED PIPE. A |
| 4 | 22730-5M4-000 | FEED PIPE. B, |
| 5 | 25422-RJ2-003 | TRANSMISSION MAGNET |
| 6 | 90030-RT4-003 | BOLT, SEALING, 10MM |
| 7 | 90471-59C-000 | PACKING, 10MM (AL-PACKING) |
| 8 | 91205-P0X-005 | OIL SEAL, 40X56X9 (NOK) |
| 9 | 91303-RAY-003 | O-RING, 12X2.4 (NOK) |
| 10 | 91305-PX4-003 | O-RING, 40X1.9 (NOK) |
| 11 | 91311-PA9-004 | O-RING, 7.7X1.9 (NOK) |
| 12 | 91314-PW4-003 | O-RING, 11X1.9 (NOK) |
| 13 | 92800-20000 | BOLT, DRAIN PLUG, 20MM |
| 14 | 94109-20000 | WASHER, DRAIN PLUG, 20MM |
| 15 | 94520-45000 | CIRCLIP, INTERNAL, 45MM |
| 16 | 95701-06018-08 | BOLT, FLANGE, 6X18 |
