Honda Vezel RV5 Electrical System Parts

Ref No Part Number Part Description 1 17136-REJ-W00 Grommet, Breather Pipe 2 17201-6Y0-018 Case Set, Air Cleaner 3 17210-6Y0-018 Cover COMP., Air Cleaner 4 17212-5R0-008 Tube, Air Cleaner 5 17212-PN3-000…

Ref No Part Number Part Description 1 17251-6HN-003 Tube, Air Intake 2 17252-6HN-003 Duct ASSY., Air Intake 3 95701-06016-08 Bolt, Flange (6X16) 4 95701-06016-08 Bolt, Flange (6X16)

Ref No Part Number Part Description 1 17212-6Y0-000 Rubber, Resonator Mounting 2 17212-PE2-000 Rubber A, Air Cleaner Case Mounting 3 17216-R3R-E00 Color, Air Cleaner 4 17230-6Y0-003 Chamber ASSY., Resonator 5…

Ref No Part Number Part Description 1 34260-3M0-J01 Light Assembly, Cargo Room 2 34400-3M0-J31 Light Assembly, Map 3 34400-3M0-N01 Light ASSY., rear map 4 34420-3M0-N01ZB Garnish assembly, rear map 5…

Ref No Part Number Part Description 1 35251-T5A-B02 Body, Switch 2 35255-TDK-J21 Switch ASSY., Lighting & Turn Signal 3 35256-TYF-J51 Switch ASSY., Wiper 4 93893-05014-08 Screw-Washer (5X14)

Ref No Part Number Part Description 1 35155-TZA-J01 Switch Assembly, Illumination Control 6 35510-3M0-J01 Switch ASSY., Hazard 8 35730-3M0-D01 Switch ASSY., Mode & HDC & EPB 10 35881-TZA-J11 Switch Assembly,…

Ref No Part Number Part Description 1 39104-T0A-A01 Bolt, Flange 5X7 2 8A500-3M0-E01 Bracket A 3 8A500-3M0-E11 Bracket B 4 8A500-3N0-JK1 Audio unit, display 5 90140-SDA-A00 Bolt Washer 5X19 6…

Ref No Part Number Part Description 1 32942-3M0-J01 Cord, LVDS Multi-View Camera Rear 2 36530-3M0-J01 Rear Multi-view Camera 4 39581-TZA-J01 ETC Unit 5 8B580-3M0-J01 ETC Antenna 6 91534-SWA-003 Clip, Connector…

Ref No Part Number Part Description 1 06351-T00-Z01 Steering Lock Assembly 2 06352-TAA-J11 Holder set, column

Ref No Part Number Part Description 1 78100-3N0-JB3 Combination Meter Assembly 2 78156-3N0-A01 Lens 3 78175-SE3-004 Rubber 4 93913-15480 Screw, Tapping (5X16) (Po)
