Front Seat Right
| Ref No. | Parts No. | Parts Name | Unit Qty |
| 1 | 04810-SB3-000 | C CLIP SET, TRIM FASTENER (30 PIECES) | 001 |
| 2 | 78050-TG7-A91 | MODULE ASSY., R. SIDE | 001 |
| 3 | 81110-TZ5-A01ZG | COVER, R. FR. CUSHION *NH900L* (NH900L NEUTRAL BLACK) | 001 |
| 4 | 81123-SZA-A01 | NUT, PAL | 002 |
| 5 | 81124-T6Z-A41 | HEATER COMP., FR. SEATBACK | 001 |
| 6 | 81125-T6Z-L71ZA | COVER SET, R. TRIM (LEATHER) (SIDE AIRBAG) *NH900L* (NH900L NEUTRAL BLACK) | 001 |
| 7 | 81127-T6Z-A41 | PAD COMP., R. FR. SEATBACK | 001 |
| 8 | 81131-T6Z-L71ZA | COVER, R. FR. SEAT CUSHION TRIM (LEATHER) *YR666L* (YR666L THREAD TRAIL ORANGE) | 001 |
| 9 | 81134-T6Z-A41 | HEATER COMP., R. FR. SEAT CUSHION | 001 |
| 10 | 81137-T6Z-A42 | PAD COMP., R. FR. SEAT CUSHION | 001 |
| 11 | 81140-T6Z-L71ZA | HEADREST ASSY., FR. SEAT (LEATHER) *YR666L* (YR666L THREAD TRAIL ORANGE) | 001 |
| 12 | 81143-T3L-A01ZH | GUIDE, HEADREST FREE *NH900L* (NH900L NEUTRAL BLACK) | 001 |
| 13 | 81144-T3L-A01ZG | GUIDE COMP., R. HEADREST LOCK *NH900L* (NH900L NEUTRAL BLACK) | 001 |
| 18 | 81237-TG7-A31ZB | COVER, R. OUTER RECLINING INNER *NH900L* (NH900L NEUTRAL BLACK) | 001 |
| 20 | 81238-TG7-A51ZB | COVER, R. OUTER RECLINING OUTER *NH900L* (NH900L NEUTRAL BLACK) | 001 |
| 22 | 81247-TZ3-A11ZF | COVER, R. INNER RECLINING INNER *NH900L* (NH900L NEUTRAL BLACK) | 001 |
| 24 | 81248-TZ3-A11ZF | COVER, R. RECLINING INNER *NH900L* (NH900L NEUTRAL BLACK) | 001 |
| 25 | 81268-TG7-A51ZB | CAP, R. OUTER LAP PRETENSIONER COVER *NH900L* (NH900L NEUTRAL BLACK) | 001 |
| 27 | 90134-SE3-003 | SCREW, TAPPING, 5X10 | 002 |
| 28 | 90321-SP0-A80 | NUT-WASHER, 6MM | 002 |
| 29 | 90610-S10-003 | CLIP, GARNISH | 001 |
| 30 | 93901-25380 | SCREW, TAPPING, 5X16 | 001 |
