Differential
| Ref No. | Parts No. | Parts Name |
| 1 | 41100-6JK-003 | DIFFERENTIAL |
| 2 | 41233-6JK-000 | FINAL DRIVEN GEAR |
| 3 | 41381-60H-000 | SPACER, 41X88X1 |
| 4 | 41441-60H-000 | SHIM A, 88MM (1.647) |
| 4 | 41442-60H-000 | SHIM B, 88MM (1.672) |
| 4 | 41443-60H-000 | SHIM C, 88MM (1.697) |
| 4 | 41444-60H-000 | SHIM D, 88MM (1.722) |
| 4 | 41445-60H-000 | SHIM E, 88MM (1.747) |
| 4 | 41446-60H-000 | SHIM F, 88MM (1.772) |
| 4 | 41447-60H-000 | SHIM G, 88MM (1.797) |
| 4 | 41448-60H-000 | SHIM H, 88MM (1.822) |
| 4 | 41449-60H-000 | SHIM I, 88MM (1.847) |
| 4 | 41450-60H-000 | SHIM J, 88MM (1.872) |
| 4 | 41451-60H-000 | SHIM K, 88MM (1.897) |
| 4 | 41452-60H-000 | SHIM L, 88MM (1.922) |
| 4 | 41453-60H-000 | SHIM M, 88MM (1.947) |
| 4 | 41454-60H-000 | SHIM N, 88MM (1.972) |
| 4 | 41455-60H-000 | SHIM O, 88MM (1.997) |
| 4 | 41456-60H-000 | SHIM P, 88MM (2.022) |
| 4 | 41457-60H-000 | SHIM Q, 88MM (2.047) |
| 4 | 41458-60H-000 | SHIM R, 88MM (2.072) |
| 4 | 41459-60H-000 | SHIM S, 88MM (2.097) |
| 4 | 41460-60H-000 | SHIM T, 88MM (2.122) |
| 4 | 41461-60H-000 | SHIM U, 88MM (2.147) |
| 4 | 41462-60H-000 | SHIM V, 88MM (2.172) |
| 4 | 41463-60H-000 | SHIM W, 88MM (2.197) |
| 4 | 41464-60H-000 | SHIM X, 88MM (2.222) |
| 4 | 41465-60H-000 | SHIM Y, 88MM (2.247) |
| 4 | 41466-60H-000 | SHIM Z, 88MM (2.272) |
| 4 | 41467-60H-000 | SHIM AA, 88MM (2.297) |
| 4 | 41468-60H-000 | SHIM AB, 88MM (2.322) |
| 5 | 90003-PA9-003 | BOLT, FLANGE, 10MM |
| 6 | 91121-60H-006 | BEARING BALL, 40X88X20.5 |
