Front Bulkhead
| Ref No. | Parts No. | Parts Name |
| 1 | 04601-3M1-T00ZZ | STAY SET, R. FR. BULKHEAD SIDE |
| 2 | 04602-3N0-300ZZ | FRAME SET, FR. BULKHEAD UPPER |
| 3 | 04603-3N0-300ZZ | CROSSMEMBER SET, FR. BULKHEAD LOWER |
| 4 | 04611-3M1-T00ZZ | STAY SET, L. FR. BULKHEAD SIDE |
| 5 | 04613-3N1-T00ZZ | BASE SET, R. HOOD HINGE |
| 6 | 04618-3N1-T00ZZ | BASE SET, L. HOOD HINGE |
| 7 | 04674-3N1-T00ZZ | EXTENSION SET, R. FR. SHOCK ABSORBER |
| 8 | 04684-3N1-T00ZZ | EXTENSION SET, L. FR. SHOCK ABSORBER |
| 10 | 60419-3M0-300ZZ | PLATE, R. FR. BULKHEAD SIDE LOWER |
| 11 | 60469-3M0-300ZZ | PLATE, L. FR. BULKHEAD SIDE LOWER |
| 12 | 60610-3N1-T00ZZ | MEMBER COMP., R. FR. WHEELHOUSE UPPER |
| 13 | 60623-3N1-T00ZZ | BRACKET, R. FR. FENDER |
| 14 | 60630-TZB-000ZZ | BASE COMP., BATTERY SETTING |
| 15 | 60650-3N1-T00ZZ | HOUSING COMP., R. FR. SHOCK ABSORBER |
| 16 | 60710-3N1-T00ZZ | MEMBER COMP., L. FR. WHEELHOUSE UPPER |
| 17 | 60723-3N1-T00ZZ | BRACKET, L. FR. FENDER |
| 18 | 60750-3N1-T00ZZ | HOUSING COMP., L. FR. SHOCK ABSORBER |
| 19 | 60810-3N1-T00ZZ | FRAME COMP., R. FR. SIDE |
| 20 | 60811-3N1-305ZZ | FRAME SET, R. FR. SIDE |
| 21 | 60812-T9A-T00ZZ | PLATE, R. FR. SIDE BACK |
| 22 | 60843-T7A-300ZZ | BRACKET, R. FR. BUMPER BEAM EXTENSION |
| 23 | 60844-3N1-305ZZ | PLATE SET, R. SIDE FRAME GUSSET |
| 24 | 60845-3N1-305ZZ | GUSSET SET, R. FR. SIDE FRAME |
| 25 | 60846-T5A-300ZZ | PATCH, R. BUMPER BEAM |
| 26 | 60848-T00-T00ZZ | SUPPORT, R. FR. BULKHEAD |
| 27 | 60910-3N1-T00ZZ | FRAME COMP., L. FR. SIDE |
| 28 | 60911-3N1-305ZZ | FRAME SET, L. FR. SIDE |
| 29 | 60912-T9A-T00ZZ | PLATE, L. FR. SIDE BACK |
| 30 | 60943-T7A-300ZZ | BRACKET, L. FR. BUMPER BEAM EXTENSION |
| 31 | 60944-T9A-T00ZZ | PLATE, L. SIDE FRAME GUSSET |
| 32 | 60945-T8N-Q00ZZ | GUSSET, L. FR. SIDE FRAME |
| 33 | 60946-T5A-300ZZ | PATCH, L. BUMPER BEAM |
| 34 | 60948-T00-T00ZZ | SUPPORT, L. FR. BULKHEAD |
| 35 | 61100-3N1-T00ZZ | DASHBOARD COMP., UPPER |
| 36 | 61140-3N1-T00ZZ | FRAME COMP., WINDSHIELD LOWER |
| 37 | 61151-3M0-300ZZ | BRACKET, R. HOOD CUSHION |
| 38 | 61154-3N1-T00ZZ | BRACKET, R. FR. FENDER RR. |
| 39 | 61156-3M0-300ZZ | BRACKET, L. HOOD CUSHION |
| 40 | 61159-3N1-T00ZZ | BRACKET, L. FR. FENDER RR. |
| 41 | 61164-3M0-300ZZ | BRACKET, R. FR. FENDER FR. |
| 42 | 61169-3M0-300ZZ | BRACKET, L. FR. FENDER FR. |
| 43 | 61500-3N1-T00ZZ | DASHBOARD COMP., LOWER |
| 44 | 74291-3N1-T00 | LID, DASHBOARD UPPER |
| 45 | 74293-3N1-T00 | INSULATOR, DASHBOARD UPPER LID |
| 46 | 90105-SV1-000 | BOLT-WASHER, 8X20 |
| 48 | 90108-S0A-003 | BOLT, FLANGE, 6X15 |
| 49 | 93404-08016-08 | BOLT-WASHER, 8X16 |
| 50 | 90122-TF0-000 | BOLT-WASHER, 6X14 (WITH GUIDE) |
| 51 | 91517-SE0-003 | CLIP, LOWER OUTER DASHBOARD INSULATOR |
| 52 | 60400-3N1-T00ZZ | BULKHEAD FRONT |
