Front Brake
| Ref No | Part Number | Part Description |
| 1 | 01463-TX4-A01 | Front Caliper Set |
| 2 | 43352-SM4-951 | Screw Bleeder |
| 3 | 43353-SD5-003 | Cap Bleeder Screw |
| 4 | 44300-TVE-H51 | Front Hub Bearing Assembly |
| 5 | 44600-T0B-A00 | Front Hub Assy |
| 6 | 45018-T3V-020 | Front Caliper Sub Assy Right |
| 7 | 45019-T3V-020 | Front Caliper Sub Assy Left |
| 8 | 45022-T3V-A02 | Front Brake Pad Set |
| 9 | 45216-TY2-A01 | Piston |
| 10 | 45235-TR0-E01 | Pin A |
| 11 | 45237-T2G-A04 | Retainer |
| 12 | 45240-SM4-003 | Bolt, Flange 10X24 |
| 13 | 45251-T3V-A01 | Front Brake Disk |
| 14 | 45255-T7A-000 | Guard, Front Brake Splashy |
| 15 | 45262-T0A-A01 | Pin assembly |
| 16 | 90107-SM4-000 | Bolt, Caliper Mounting 12X21 |
| 17 | 90113-S84-901 | Bolt, Wheel Rocknel Fastener |
| 17 | 90113-SD4-901 | Bolt, Wheel Meira |
| 17 | 90113-SD4-902 | Bolt, Wheel Sagatetsukou |
| 17 | 90113-SJK-901 | Bolt, Wheel Thai Meira |
| 18 | 90681-T6A-J00 | Circuit, Special internal 91MM |
| 19 | 93600-06014-0H | Screw, Flat 6X14 |
| 20 | 93892-05012-08 | Screw-Washer (5X12) |
