Timing Chain Cover
| Ref No. | Parts No. | Parts Name |
| 1 | 11410-62W-000 | CHAIN CASE |
| 2 | 11412-6Y0-000 | CHAIN COVER |
| 3 | 11413-5R0-003 | O-RING, CHAIN CASE (NOK) |
| 6 | 15200-5R0-000 | OIL LEVEL PIPE |
| 7 | 15810-62W-T01 | SPOOL VALVE |
| 8 | 15815-5R0-003 | SPOOL VALVE FILTER |
| 9 | 17115-PWA-000 | RUBBER, ENGINE COVER MOUNTING |
| 10 | 17116-PWA-000 | COLLAR, ENGINE COVER |
| 11 | 32747-5R0-900 | STAY, ENGINE WIRE HARNESS CHAIN CASE LOWER |
| 12 | 37260-RNA-A01 | SENSOR, OIL PRESSURE |
| 13 | 95701-08025-08 | BOLT, FLANGE, 8X25 |
| 14 | 90015-PF0-000 | BOLT, FLANGE, 8X53 |
| 15 | 90021-PWA-003 | BOLT, SPECIAL, 8X41 |
| 16 | 90041-6Y0-000 | BOLT, STUD, 14X65 |
| 17 | 90107-P4V-000 | BOLT, FLANGE, 8X40 |
| 18 | 90380-6Y0-000 | BOLT, STUD, 14X117 |
| 19 | 91212-5K9-003 | OIL SEAL, 40X55X7 (NOK) |
| 20 | 91306-5K0-A01 | O-RING, 92.4X2.8 |
| 21 | 91309-5R0-003 | O-RING, 15X2.5 (NOK) |
| 22 | 91319-PAA-A01 | O-RING, 13X1.5 |
| 23 | 93404-06020-08 | BOLT-WASHER, 6X20 |
| 24 | 94302-04065 | PIN B, DOWEL, 4X6.5 |
| 25 | 95701-06012-08 | BOLT, FLANGE, 6X12 |
| 26 | 95701-06012-08 | BOLT, FLANGE, 6X12 |
| 27 | 95701-06020-08 | BOLT, FLANGE, 6X20 |
| 28 | 95701-06020-08 | BOLT, FLANGE, 6X20 |
| 29 | 95701-06055-08 | BOLT, FLANGE, 6X55 |
| 30 | 95701-06075-08 | BOLT, FLANGE, 6X75 |
| 31 | 11430-62W-000 | ELECTRIC VTC COVER |
| 32 | 14320-6MA-J01 | ELECTRIC VTC MOTOR |
