Seatbelts Front
| Ref No. | Parts No. | Parts Name |
| 1 | 81115-TZA-J01 | NUT, FLANGE, 7/16″ |
| 2 | 81220-TZA-J01 | WASHER, WAVE, 17MM |
| 3 | 81441-S2G-N71 | COLLAR (7.5H) |
| 4 | 81441-S4N-J01 | COLLAR (6.5H) |
| 5 | 81441-S50-J51 | COLLAR (5H) |
| 7 | 04813-3M4-M00ZA | BUCKLE SET, R. FR. SEATBELT *NH900L* (NH900L NEUTRAL BLACK) |
| 8 | 81460-T5L-T01ZA | ADJUSTER, SHOULDER SLIDE *NH882L* (NH882L PLATINUM GRAY) |
| 9 | 81461-T5A-J01ZB | COVER, SHOULDER SLIDE ADJUSTER *NH882L* (NH882L PLATINUM GRAY) |
| 10 | 81462-T5A-J00ZB | COVER, SLIDER *NH882L* (NH882L PLATINUM GRAY) |
| 11 | 04818-3M4-M00ZB | SEATBELT OUTER, L FR *NH882L* (NH882L PLATINUM GRAY) |
| 12 | 04816-3M4-M00ZA | SEATBELT BUCKLE, L FR *NH900L* (NH900L NEUTRAL BLACK) |
| 13 | 90142-TYF-000 | BOLT, 7/16″X27 |
| 14 | 90140-TZA-000 | BOLT-WASHER, 8X25 |
| 15 | 90142-T9A-T01 | BOLT, 7/16″X38 |
| 17 | 90142-T9A-T01 | BOLT, 7/16″X38 |
| 18 | 90142-TEA-T01 | BOLT, 7/16″X26.2 |
| 19 | 90142-TEA-T01 | BOLT, 7/16″X26.2 |
| 20 | 90543-S2G-K31 | WASHER, PLAIN |
| 22 | 93405-06016-08 | BOLT-WASHER, 6X16 |
| 23 | 93405-06016-08 | BOLT-WASHER, 6X16 |
| 24 | 04814-3M4-M00ZB | SEATBELT OUTER SET, R. FR *NH882L* (NH882L PLATINUM GRAY) |
