Side Lining
| Ref No. | Parts No. | Parts Name |
| 1 | 1J621-6HP-020 | AIR INTAKE DUCT SUB ASSY. A, |
| 2 | 1J627-6HP-000 | INTAKE DUCT JOINT |
| 3 | 1J681-6HP-000 | IPU OUTLET DUCT COMP. A, R |
| 4 | 1J682-6HP-010 | OUTLET DUCT JOINT, R |
| 5 | 83308-S2G-003 | FLOOR LID LATCH |
| 6 | 84602-3N1-T01ZA | TOOL BOX LID *NH900L* (NH900L NEUTRAL BLACK) |
| 7 | 84603-3M0-J01ZA | Fuel Maintenance Lid, R*NH900L* (NH900L NEUTRAL BLACK) |
| 8 | 84605-3N1-T01ZA | Rear Side Trim Panel TRUNK SIDE *NH900L* (NH900L NEUTRAL BLACK) |
| 9 | 84614-TLA-A01ZA | TIE DOWN HOOK *NH900L* (NH900L NEUTRAL BLACK) |
| 11 | 84615-3M1-T00 | BRACKET COMP., R. TIE DOWN HOOK |
| 12 | 84640-3M1-T01ZA | PANEL LINING Rear *NH900L* (NH900L NEUTRAL BLACK) |
| 13 | 84652-3M0-J01ZA | HOOK, CONVENIENCE *NH900L* (NH900L NEUTRAL BLACK) |
| 14 | 84653-3M0-J01ZA | LID, L. DAMPER MAINTENANCE *NH900L* (NH900L NEUTRAL BLACK) |
| 15 | 84655-3N1-T01ZA | LINING COMP., L. TRUNK SIDE *NH900L* (NH900L NEUTRAL BLACK) |
| 17 | 84665-3M1-T00 | BRACKET COMP., L. TIE DOWN HOOK |
| 18 | 90132-SS0-000 | SCREW, TAPPING, 4X10 (PO) |
| 19 | 91560-S1C-E01 | CLIP, ROOF LINING (NATURAL) |
| 20 | 91560-SZW-003 | CLIP, DOOR LINING (APPLE GREEN) |
| 22 | 93403-06016-08 | BOLT-WASHER, 6X16 |
