Front Bulkhead
| Ref No | Part Number | Part Description |
| 1 | 04601-3M0-300ZZ | Front Bulkhead Side Stay, R |
| 2 | 04602-3N0-300ZZ | Frame Set, Front Upper Bulkhead |
| 3 | 04603-3N0-300ZZ | Crossmember Set, Front Bulkhead Lower |
| 4 | 04611-3M0-300ZZ | Stay, L. Front Bulkhead Side |
| 5 | 04613-3M0-300ZZ | Base Set, R. Bonnet Hinge |
| 6 | 04618-3N0-300ZZ | Base Set, L. Bonnet Hinge |
| 7 | 04674-3N0-300ZZ | Extension Set, R. Front Damper |
| 8 | 04684-3N0-300ZZ | Extension Set, L. Front Damper |
| 9 | 60400-3N0-300ZZ | Bulkhead COMP., Front |
| 10 | 60419-3M0-300ZZ | Plate, R. Front Bulkhead Side Lower |
| 11 | 60469-3M0-300ZZ | Plate, L. Front Bulkhead Side Lower |
| 12 | 60610-3M0-300ZZ | Member COMP., R. Front Wheelhouse Upper |
| 13 | 60623-3M0-300ZZ | Bracket, R. Front Fender |
| 14 | 60630-TZB-000ZZ | Base COMP., Battery Setting |
| 15 | 60650-3N0-300ZZ | Housing COMP., R. Front Damper |
| 16 | 60710-3M0-300ZZ | Front Wheelhouse Upper Member, L. |
| 17 | 60723-3M0-300ZZ | Bracket, L. Front Fender |
| 18 | 60750-3N0-300ZZ | Housing COMP., L. Front Damper |
| 19 | 60810-3M0-300ZZ | Frame COMP., R. Front Side |
| 20 | 60811-3M0-305ZZ | Frame Set, R. Front Side |
| 21 | 60812-T5A-300ZZ | Plate, R. Front Side Back |
| 22 | 60843-T7A-300ZZ | Bracket, R. Front Bumper Beam Extension |
| 23 | 60844-TZB-305ZZ | Plate Set, R. Side Frame Garnish |
| 24 | 60845-3N0-305ZZ | Garnet Set, R. Front Side Frame |
| 25 | 60846-T5R-A00ZZ | Patch, R. Bumper Beam |
| 26 | 60848-T00-T00ZZ | Support, R. Front Bulkhead |
| 27 | 60910-3N0-300ZZ | Frame COMP., L. Front Side |
| 28 | 60911-3N0-305ZZ | Frame Set, L. Front Side |
| 29 | 60912-T5A-300ZZ | Plate, L. Front Side Back |
| 30 | 60943-T7A-300ZZ | Bracket, L. Front Bumper Beam Extension |
| 31 | 60944-T8M-G00ZZ | Plate, L. Side Frame Bracket |
| 32 | 60945-TZA-300ZZ | Gasket, L. Front Side Frame |
| 33 | 60946-T5R-A00ZZ | Patch, L. Bumper Beam |
| 34 | 60948-T00-T00ZZ | Support, L. Front Bulkhead |
| 35 | 61100-3N0-300ZZ | Dashboard COMP., Upper |
| 36 | 61140-3N0-300ZZ | Frame COMP., Windshield Lower |
| 37 | 61151-3M0-300ZZ | Bracket, R. Bonnet Cushion |
| 38 | 61154-3M0-300ZZ | Bracket, R. Front Fender Rear |
| 39 | 61156-3M0-300ZZ | Bracket, L. Bonnet Cushion |
| 40 | 61159-3M0-300ZZ | Bracket, L. Front Fender Rear |
| 41 | 61164-3M0-300ZZ | Bracket, R. Front Fender Front |
| 42 | 61169-3M0-300ZZ | Bracket, L. Front Fender Front |
| 43 | 61500-3N0-300ZZ | Dashboard COMP., Lower |
| 44 | 74291-3M0-000 | Lid, Dashboard Upper |
| 45 | 74293-3M0-000 | Insulator, Dashboard upper lid |
| 46 | 90105-634-000 | Bolt Washer 8X20 |
| 47 | 90109-TZA-000 | Bolt Washer 6X16 |
| 48 | 90110-T5A-J00 | Bolt Washer 8X21 |
| 49 | 90122-TF0-000 | Bolt Washer 6X14 |
| 50 | 91517-SE0-003 | Clip, Lower Outer Dashboard Insulator |
