EGR Valve
| Ref No | Part Number | Part Description |
| 1 | 12210-PZ1-003 | Seal A, Valve Stem Arai |
| 1 | 12210-PZ1-004 | Seal A, Valve Stem NOK |
| 2 | 12211-PZ1-003 | Seal B, Valve Stem Arai |
| 2 | 12211-PZ1-004 | Seal B, Valve Stem NOK |
| 3 | 12251-5R0-J01 | Gasket COMP., Cylinder Head |
| 4 | 12511-5P6-000 | Plate, cylinder head intake |
| 5 | 12512-5R0-J50 | Plate, Cylinder Head Exhaust |
| 6 | 12513-5R0-000 | Cover, Camshaft Holder |
| 7 | 15831-5R0-000 | Orifice ASSY., Oil path |
| 8 | 18011-6L2-010 | Valve Set, EGR |
| 9 | 18715-PB2-000 | Gasket, EGR Valve Ishino Gasket |
| 10 | 18718-5R0-J50 | Passage, EGR valve |
| 11 | 18720-6Y0-J01 | Cooler COMP., EGR |
| 12 | 18722-5R0-J01 | Gasket, EGR cooler outlet |
| 13 | 18723-5R0-J01 | Gasket, EGR Passage |
| 14 | 37510-59B-J01 | Sensor TDC |
| 15 | 90008-PWA-003 | Bolt washer 9X155 |
| 16 | 90025-5R0-000 | Bolt, Stud 8X32 |
| 17 | 90026-RMX-000 | Bolt, Stud 8X22 |
| 18 | 91301-5R0-003 | O-Ring A, Head Plate |
| 19 | 91302-5K0-A01 | O-Ring 16.8X1.9 |
| 20 | 91303-5R1-003 | O-ring B, head plate |
| 21 | 91333-PNA-003 | O-ring 15X1.9 |
| 22 | 92900-08022-1B | Bolt 2, Stud (8X22) |
| 23 | 92900-08080-0B | Bolt, Stud 8X80 |
| 24 | 94050-06080 | Nut, Flange (6Mm) |
| 25 | 94050-08080 | Nut, Flange (8Mm) |
| 26 | 94301-14200 | Pin A, Dowel (14X20) |
| 27 | 95701-06014-08 | Bolt, Flange (6X14) |
| 28 | 95701-06016-08 | Bolt, Flange (6X16) |
| 29 | 95701-06020-08 | Bolt, Flange (6X20) |
| 30 | 95701-08020-08 | Bolt, Flange (8X20) |
| 31 | 95701-08030-08 | Bolt, Flange (8X30) |
| 32 | 95701-08055-08 | Bolt, Flange (8X55) |
| 33 | 95701-08070-08 | Bolt, Flange (8X70) |
| 34 | 95701-08080-08 | Bolt, Flange (8X80) |
