Sensor and Pipe
| Ref No | Part Number | Part Description |
| 1 | 1A710-5M4-003 | Sensor Assembly, ATF Temperature |
| 2 | 22713-5M4-000 | Guide A, Feed Pipe |
| 3 | 22715-5M4-000 | Pipe COMP. A, Feed |
| 4 | 22730-5M4-000 | Pipe COMP. B, Feed |
| 5 | 25422-RJ2-003 | Magnet ASSY., Transmission |
| 6 | 90030-RT4-003 | Bolt, Sealing 10MM |
| 7 | 90471-59C-000 | Padkin 10MM Aluminum |
| 8 | 91205-P0X-005 | Oil Seal 40X56X9 NOK |
| 9 | 91303-RAY-003 | O-Ring 12X2.4 NOK |
| 10 | 91305-PX4-003 | O-Ring (40X1.9) (Nok) |
| 11 | 91311-PA9-004 | O-Ring (7.7X1.9) (Nok) |
| 12 | 91314-PW4-003 | O-Ring 11X1.9 NOK |
| 13 | 92800-20000 | Bolt, Drain Plug 20MM |
| 14 | 94109-20000 | Washer, Drain Plug (20Mm) |
| 15 | 94520-45000 | Circlip (Inner) (45Mm) |
| 16 | 95701-06018-08 | Bolt, Flange (6X18) |
