Rear Doo Lock
| Ref No. | Parts No. | Parts Name |
| 1 | 72120-3M0-J02ZA | HANDLE ASSY., R. INSIDE *NH900L* (NH900L NEUTRAL BLACK) |
| 2 | 72135-SDA-A01 | STRIKER ASSY., DOOR LOCK |
| 3 | 72141-TK6-004 | BUSH, R. JOINT (BROWN) (LEFT HAND SIDE) |
| 4 | 72160-3M0-J02ZA | HANDLE ASSY., L. INSIDE *NH900L* (NH900L NEUTRAL BLACK) |
| 5 | 72181-TK6-004 | BUSH, L. JOINT (YELLOW) (RIGHT HAND SIDE) |
| 6 | 72610-T00-T01 | LATCH ASSY., R. RR. DOOR POWER |
| 7 | 72612-T0A-A01 | CAP, R. CHILD LOCK |
| 8 | 72613-3M0-305 | ROD SET, R. RR. DOOR LATCH |
| 9 | 72631-3M0-J01 | CABLE, RR. INSIDE HANDLE |
| 10 | 72633-3M0-J01 | CABLE, RR. DOOR LOCK |
| 11 | 72640-3M0-J01 | HANDLE ASSY., R. RR. DOOR OUTSIDE |
| 12 | 72650-T00-T01 | LATCH ASSY., L. RR. DOOR POWER |
| 13 | 72652-T0A-A01 | CAP, L. CHILD LOCK |
| 14 | 72653-3M0-305 | ROD SET, L. RR. DOOR LATCH |
| 15 | 72680-3M0-J01 | HANDLE ASSY., L. RR. DOOR OUTSIDE |
| 16 | 90103-TBA-000 | BOLT, DOOR LATCH, 6MM |
| 17 | 90120-T2A-000 | BOLT, LOCK STRIKER |
| 18 | 90141-SDA-000 | SCREW, TAPPING, 5X12 |
| 19 | 90662-TVA-A01 | GROMMET, SCREW, 5MM (SEAL) |
| 20 | 90691-TBA-A01 | CLIP, LOCK CABLE |
| 21 | 93403-06012-08 | BOLT-WASHER, 6X12 |
