Control Unit Cabin1
| Ref No. | Parts No. | Parts Name |
| 1 | 06370-T20-X03 | WIRELESS CHARGER UNIT |
| 2 | 37410-3N1-Z11 | Acoustic Vehicle Alerting Control Unit (REWRITABLE) |
| 3 | 37411-3N0-J00 | BRACKET, AVAS UNIT |
| 4 | 38150-3M0-G51 | SECURITY HORN |
| 5 | 38200-3M0-J21 | Under-Dash Fuse |
| 6 | 38221-SNA-A31 | FUSE, BLADE (7.5A) |
| 7 | 38221-SNA-A41 | FUSE, BLADE (10A) |
| 8 | 38221-SNA-A51 | FUSE, BLADE (15A) |
| 9 | 38221-SNA-A61 | FUSE, BLADE (20A) |
| 10 | 38221-TZ3-A01 | FUSE, BLADE (5A) |
| 11 | 38850-3M0-T02 | RELAY MODULE SEMICONDUCTOR |
| 12 | 38851-3M0-000 | BRACKET, SEMICONDUCTOR RELAY MODULE |
| 13 | 38890-3N0-Y51 | MANAGEMENT UNIT, INTEGRATED (REWRITABLE) |
| 14 | 38891-3M0-000 | BRACKET, INTEGRATED MANAGEMENT UNIT |
| 15 | 38970-3M0-E01 | Automatic Lighting and Rain Sensor |
| 16 | 39794-S10-003 | WASHER MTOR RELAY(5P) (MICRO ISO) (MITSUBA) |
| 17 | 39794-SDA-A02 | RELAY ASSY., POWER (MICRO ISO) (DENSO) (HEATER MOTOR) |
| 29 | 90137-SF1-000 | BOLT-WASHER, 6X25 |
| 31 | 90361-SV4-003 | NUT, PAINT CUTTING, 6MM |
| 32 | 93913-14220 | SCREW, TAPPING, 4X12 |
| 37 | 95701-06012-08 | BOLT, FLANGE, 6X12 |
| 38 | 95701-06012-08 | BOLT, FLANGE, 6X12 |
| 39 | 95701-08012-08 | BOLT, FLANGE, 8X12 |
