Front Bumper
| Ref No | Part Number | Part Description |
| 1 | 39681-3M0-N01 | Retainer, Parking Sensor L |
| 2 | 39681-3M0-N11 | Retainer, Parking Sensor R |
| 3 | 71100-3M0-J50ZA | Face Assy., Front Bumper R565M Premium Crystal Red Metallic |
| 3 | 71100-3M0-J50ZB | Face Assy., Front Bumper NH912P Slate Gray Pearl |
| 3 | 71100-3M0-J50ZC | Face Assy., Front Bumper NH902P Premium Sunlight White Pearl |
| 3 | 71100-3M0-J50ZD | Face Assy., Front Bumper NH883P Platinum White Pearl |
| 3 | 71100-3M0-J50ZE | Face Assy., Front Bumper NH731P Crystal Black Pearl |
| 3 | 71100-3M0-J50ZF | Face Assy., Front Bumper G555P Botanical Green Pearl |
| 3 | 71100-3M0-J50ZG | Face Assy., Front Bumper B645P Seabed Blue Pearl |
| 4 | 71106-3M0-J50ZA | Cover, Front Towing Hook R565M Premium Crystal Red Metallic |
| 4 | 71106-3M0-J50ZB | Cover, Front Towing Hook NH912P Slate Gray Pearl |
| 4 | 71106-3M0-J50ZC | Cover, Front Towing Hook NH902P Premium Sunlight White Pearl |
| 4 | 71106-3M0-J50ZD | Cover, Front Towing Hook NH883P Platinum White Pearl |
| 4 | 71106-3M0-J50ZE | Cover, Front Towing Hook NH731P Crystal Black Pearl |
| 4 | 71106-3M0-J50ZF | Cover, Front Towing Hook G555P Botanical Green Pearl |
| 4 | 71106-3M0-J50ZG | Cover, Front Towing Hook B645P Seabed Blue Pearl |
| 5 | 71110-3M0-000ZB | Garnish, Front Bumper Upper R565M Premium Crystal Red Metallic |
| 5 | 71110-3M0-000ZD | Garnish, Front Bumper Upper NH902P Premium Sunlight White Pearl |
| 5 | 71110-3M0-000ZE | Garnish, Front Bumper Upper NH883P Platinum White Pearl |
| 5 | 71110-3M0-000ZF | Garnish, Front Bumper Upper NH731P Crystal Black Pearl |
| 5 | 71110-3M0-000ZH | Garnish, Front Bumper Upper NH912P Slate Gray Pearl |
| 5 | 71110-3M0-000ZJ | Garnish, Front Bumper Upper G555P Botanical Green Pearl |
| 5 | 71110-3M0-000ZK | Garnish, Front Bumper Upper B645P Seabed Blue Pearl |
| 6 | 71130-3M0-000ZZ | Front Bumper Beam COMP |
| 7 | 71140-3M0-901 | Garnish, R. Front Fog Light |
| 8 | 71141-3M0-J01 | Garnish, R. Front Fog Light |
| 9 | 71150-3N0-J50 | Grill ASSY., Front Bumper Lower |
| 10 | 71160-3M0-J00 | Front Bumper Lower Face Assy |
| 11 | 71161-T7A-000 | Garnish, R. Front Bumper Beam |
| 12 | 71166-T7A-000 | Garnish, L. Front Bumper Beam |
| 13 | 71190-3M0-901 | Garnish, L. Front Fog Light |
| 14 | 71191-3N0-J01 | Garnish, L. Front Fog Light |
| 15 | 71230-3M0-003 | Front Bumper Side Spacer, R |
| 16 | 71240-3M0-000 | Beam, R. front bumper corner upper |
| 17 | 71250-3M0-000 | Beam COMP., Front Bumper Center Upper |
| 18 | 71253-3M0-300 | Stay A, Stiffener Upper Beam Center |
| 19 | 71280-3M0-003 | Spacer, L. Front Bumper Side |
| 20 | 71290-3M0-000 | Beam, L. front bumper corner upper |
| 21 | 71325-3M0-000 | Plate, R. Front Side Induction |
| 22 | 71355-3M0-J00 | Plate, Front bumper upper induction |
| 23 | 71375-3M0-000 | Plate, L. Front Side Induction |
| 24 | 90110-T5A-J00 | Bolt Washer 8X21 |
| 25 | 90113-SJA-A00 | Screw, Tapping 5X14 |
| 26 | 90144-TL0-G00 | Bolt, Bumper |
| 27 | 90675-SA5-003 | Nut, Clip (6Mm) |
| 28 | 90682-SDA-A01 | Grommet, Screw 5MM |
| 29 | 91501-TR0-003 | Clip, Inner Fender |
| 30 | 91505-TM8-003 | Clip, Bumper |
| 31 | 93405-06016-04 | Bolt Washer 6X16 |
| 32 | 93903-25320 | Screw, Tapping (5X16) |
| 33 | 93913-242J0 | Screw, Tapping (4X12) (Po) |
